Lathes

SN 50 C/2000
TOS Trenčín
Inventory number: 221313

Swing over bed: 500 mm
Distance between centres: 2000 mm
Max. weight of workpiece: 600 kg
Swing over cross slide: 270 mm
Main motor power: 5,5 kW
Machine dimensions l x w x h: 1100 x 3575 mm

SL 20 HE
Haas Automation
Inventory number: 221676

YOM:2004
Control system Haas:
Turn table diameter: 241 mm
Turning lenght: 508 mm
Sloping bed: YES
Spindle bore: 76 mm
Turret head: YES

SL 20 THE
Haas Automation
Inventory number: 221733

YOM:2006
Control system Haas:
Turn table diameter: 241 mm
Turning lenght: 508 mm
Sloping bed: YES
Swing over bed: 584 mm
Distance between centres: 610 mm

VDZ 120
Scherer Feinbau
Inventory number: 221307

YOM:2004
Control system Siemens: Sinumerik 840 D
Turn table diameter: 210 mm
Turning lenght: 275 mm
Sloping bed: YES
Spindle bore: mm
Turret head: YES

NEF 320
Gildemeister
Inventory number: 221494

Control system Heidenhain: Manual Plus 3110
Turn table diameter: 320 mm
Turning lenght: 750 mm
Sloping bed: NO
Spindle bore: 50 mm
Turret head: NO

M 32 V
Citizen
Inventory number: 221113

YOM:2011
Control system CINCOM: M6B
Turn table diameter: 32 mm
Turning lenght: 325 mm
Sloping bed: NO
Y axis: YES
Travel Y-axis (lathe): 275 mm

DIAMOND 32 CSL
PO LY GIM
Inventory number: 201563

YOM:2012
Max. length of workpiece: 268 mm
Swing over bed: 35 mm
Control system Mitsubishi: M 65
Cooling through spindle: YES
Pressure of cooling: 40 bar
Axis B: ANO °

Emcoturn - ET
EMCO
Inventory number: 221195

YOM:2004
Control system Siemens: Sinumerik 810
Turning lenght: 1000 mm
Swing over bed: 500 mm
Spindle taper: ASA 8 .
Spindle bore: 105 mm
Spindle speed: 0 - 4000 /min.

GS - 260 MS
Goodway
Inventory number: 221103

YOM:2003
Control system Fanuc: 18i-TB
Turn table diameter: 400 mm
Turning lenght: 570 mm
Sloping bed: YES
Spindle bore: mm
Turret head:

SV 18 RA
KOVOSVIT MAS, a.s.
Inventory number: 221322

Swing over bed: 380 mm
Distance between centres: 1000 mm
Max. weight of workpiece: 300 kg
Swing over cross slide: 215 mm
Spindle speed: 30 - 2800 /min.
Machine dimensions l x w x h: 2720x950x1210 mm

SUN 125/3000 CNC
ŠKODA MACHINE TOOL a.s.
Inventory number: 201355

YOM:1994
Control system Siemens: Sinumerik 810
Turn table diameter: 1320 mm
Turning lenght: 3000 mm
Sloping bed: NO
Spindle bore: 140 mm
Turret head: NO

NLX 2000/500
DMG MORI
Inventory number: 221643

YOM:2021
Turn table diameter: 366 mm
Turning lenght: 510 mm
Sloping bed: YES
Y axis: YES
Travel Y-axis: +-50 mm
Counterspindle: YES

CKN 1120IV
Push-Ningjiang Machine Tool Co., Ltd
Inventory number: 211513

YOM:2011
Control system Mitsubishi:
Turn table diameter: 20 mm
Turning lenght: 200 mm
Sloping bed: NO
Y axis: YES
Travel Y-axis (lathe): mm

PL 3060
Primero
Inventory number: 221470

YOM:2015
Control system Fanuc: 0i - TD
Turn table diameter: 470 mm
Turning lenght: 1500 mm
Sloping bed: NO
Y axis: NO
Counterspindle: NO

CUTEX-180AL YSMC
Hwacheon Machinery
Inventory number: 181843

YOM:2017
Control system Fanuc: 0i - TD
Turn table diameter: 300 mm
Turning lenght: 478,5 mm
Sloping bed: YES
Y axis: YES
Travel Y-axis (lathe): 55 mm

CK 6150X1500
Unknown
Inventory number: 221346

YOM:2021
Control system Siemens: Sinumerik 808 D
Turn table diameter: 500 mm
Turning lenght: 1500 mm
Sloping bed: NO
Spindle bore: 82 mm
Turret head: YES

L 20
Citizen
Inventory number: 211280

YOM:2001
Turn table diameter: 20 mm
Turning lenght: 200 mm
Sloping bed: NO
Y axis: YES
Counterspindle: YES
Spindle bore: mm

HI-TECH 450AL YMC
Hwacheon Machinery
Inventory number: 201504

YOM:2014
Control system Fanuc: 0i - TD
Turn table diameter: 700 mm
Turning lenght: 1227 mm
Sloping bed: YES
Y axis: YES
Travel Y-axis (lathe): 120 (60) mm

WIA L 200 SY
Hyundai
Inventory number: 201927

YOM:2014
Control system Fanuc: Fanuc 31i
Turn table diameter: 550 mm
Turning lenght: 530 mm
Sloping bed: YES
Y axis: YES
Travel Y-axis (lathe): +-40 mm

M 30 G Millturn
WFL Millturn
Inventory number: 191504

YOM:1999
Control system Siemens: Sinumerik 840 C
Turn table diameter: 520 mm
Turning lenght: 1050 mm
Sloping bed: YES
Y axis: YES
Travel Y-axis (lathe): 160 mm

SF 50/1900
Fermat
Inventory number: 221164

YOM:2005
Control system Fanuc: 0i Mate - TC
Turn table diameter: 500 mm
Turning lenght: 1900 mm
Sloping bed: YES
Spindle bore: mm
Turret head: NO

SL-60 AMC
MORI SEIKI
Inventory number: 211616

YOM:1993
Control system Fanuc: 0i-MF
Turn table diameter: 660 mm
Turning lenght: 3500 mm
Sloping bed: YES
Y axis: NO
Counterspindle: NO

SPRY 40 CNC
TAJMAC-ZPS, a.s.
Inventory number: 161667

YOM:1991
Control system Mefi: - - -
Turn table diameter: 110 mm
Turning lenght: 300 mm
Sloping bed: NO
Spindle bore: 50 mm
Max. bar diameter: 40 mm

SV 18 R
TOS Trenčín
Inventory number: 221316

YOM:1992
Swing over bed: 380 mm
Distance between centres: 1000 mm
Max. weight of workpiece: 300 kg
Main motor power: 6 kW
Machine weight: 1910 kg
Machine dimensions l x w x h: 3020x950mm mm

C 10 MB
Unknown
Inventory number: 221314

YOM:1974
Swing over bed: 560 mm
Distance between centres: 2000 mm
Max. weight of workpiece: kg
Swing over cross slide: 330 mm
Main motor power: 7,5 kW
Machine weight: 2800 kg

12345

Lathe – is a mechanical device that uses a chip machining to change a shape of the material or component by rotation or cutting into its final product (semi-finished product).  Using the lathe, it is possible to produce rotary parts, drill holes, cut external and internal threads.

The material (product) is clamped in the chuck. The lathe is produced in several dimensions, according to turntable diameter or turning length. Other equipment can be a revolver head, milling head, counter spindle, tailstock, chip conveyor (for extracting metal chips), cooling system (during turning a lot of heat is generated, which must be cooled. The cooling can be internal or external and according to its strength is expressed in bars).In case of CNC lathes. For numerically controlled lathes, if the manufacturer does not have its own system, it is possible to choose the system which is commonly used, for example: Fanuc, Siemens, Heidenhain or Fagor.

Types of lathes:

  • Center type lathes
  • Facing lathes
  • Semi-automatic copying lathes
  • Vertical lathes (carousels)
  • Revolver type (poloautomaty, jednovřetenové, několikavřetenové)
  • CNC lathes
  • Special

The regular lathe consists of following parts: beds, spindle, support, tailstock spindle or sliding gearbox.

Basic division of the inclination of the lathe bed:

  • horizontal or sloping (inclination 45 degrees)
  • sliding or linear

Clamping part – it is usually formed by a chuck on one side and tailstock on the other, or a chuck and second clamping part by a counter spindle.

Cutting part – formed by a cutting wedge attached to the longitudinal part - the Z axis.

The transverse part (perpendicular to the axis of the spindle) designated as the X-axis, or the automatic tool head, also usually located on the transverse feed on the machine.

Other axes, used especially in case of CNC lathes:

  • axis C1 (indexed spindle position,
  • axis C2 (indexed axis of the  counter spindle)
  • axis Y (Axis Y enables movement of tool perpendicular to axis Z and machining with live tools)
  • axis B (indexed support axis)

The machine can be erupted with a measuring tool probe (automatically or manually foldable).

According to the technological operation, turning is focused on processing of:

  • Cylindrical surfaces
  • Front surfaces
  • Conical surfaces
  • Threads

There are several hundreds manufacturers in the world, among the most popular in Czech republic are: TOS, MAZAK, DOOSAN, ŠKODA, OKUMA, GILDEMEISTER, HAAS, KOVOSVIT, GOODWAY, TAJMAC-ZPS.
