Borers horizontal

DIXI 75 CNC
Dixi
Inventory number: 241076

YOM:1968
Control system Heidenhain: TNC 620
Diameter of working spindle: 75 mm
Travel X-axis: 740 mm
Travel Y-axis: 600 mm
Spindle speed: 0 - 1600 /min.
Cooling through spindle: NO

W 100 A
TOS Varnsdorf
Inventory number: 231964

YOM:1969
Diameter of working spindle: 100 mm
Travel X-axis: 1600 mm
Travel Y-axis: 1120 mm
Spindle speed: 0 - 1120 /min.
Cooling through spindle: NO
Spindle travel - W axis: 900 mm

WRF 130 CNC
Fermat
Inventory number: 231250

YOM:2008
Control system Heidenhain: TNC 530
Diameter of working spindle: 130 mm
Travel X-axis: 8000 mm
Travel Y-axis: 3000 mm
Spindle speed: 10 - 3000 /min.
Spindle travel - W axis: 730 mm

W 100 A
TOS Varnsdorf
Inventory number: 191457

Diameter of working spindle: 100 mm
Travel X-axis: 1600 mm
Travel Y-axis: 1120 mm
Spindle speed: 7 - 1120 /min.
Cooling through spindle: NO
Spindle travel - W axis: 900 mm

WFQ 80 NCA
TOS Varnsdorf
Inventory number: 091466

YOM:1988
Diameter of working spindle: 80 mm
Travel X-axis: 1600 mm
Travel Y-axis: 1000 mm
Travel Z-axis: - mm
Spindle travel - W axis: 950 mm
Spindle speed: 14 - 2240 /min.

40T
Lucas
Inventory number: 182013

YOM:2018
Control system Fanuc: 0i-MF
Diameter of working spindle: 130 mm
Travel X-axis: 3657 mm
Travel Y-axis: 3048 mm
Spindle speed: 10 - 3000 /min.
Cooling through spindle: YES

WFC 10 CNC
Fermat
Inventory number: 231853

YOM:2014
Control system Heidenhain: TNC 530
Diameter of working spindle: 110 mm
Travel X-axis: 2000 mm
Travel Y-axis: 2000 mm
Spindle speed: 10 - 3000 /min.
Cooling through spindle: YES

W 100 A
TOS Varnsdorf
Inventory number: 231864

YOM:1998
Diameter of working spindle: 100 mm
Travel X-axis: 1600 mm
Travel Y-axis: 1120 mm
Spindle speed: 0 - 1120 /min.
Cooling through spindle: NO
Spindle travel - W axis: 900 mm

Microcut HBM-4
Buffalo Machinery
Inventory number: 221640

YOM:2017
Control system Fanuc: 31i - B
Diameter of working spindle: 110 mm
Travel X-axis: 2200 mm
Travel Y-axis: 1600 mm
Spindle speed: 35 - 3000 /min.
Cooling through spindle: YES

AFP 180
Titan
Inventory number: 221138

YOM:2009
Control system Fanuc: Fanuc 32i
Diameter of working spindle: 180 mm
Travel X-axis: 9130 mm
Travel Y-axis: 3980 mm
Z axis travel: 1900 mm/min
Axis W: 1200 mm

AFP 180
MITSUBISHI ELECTRIC
Inventory number: 241054

Control system Siemens: Sinumerik 840 D
Diameter of working spindle: 180 mm
Travel X-axis: 13 000 mm
Travel Y-axis: 4 500 mm
Spindle speed: 2 - 420 /min.
Spindle travel - W axis: 1 350 mm

BFK 160
UNION
Inventory number: 201580

YOM:1980
Diameter of working spindle: 160 mm
Travel X-axis: 3000 mm
Travel Y-axis: 2700 mm
Spindle speed: - /min.
Cooling through spindle:
Spindle travel - W axis: 300 mm

WHN 9 B
TOS Varnsdorf
Inventory number: 231135

YOM:1981
Diameter of working spindle: 90 mm
Travel X-axis: 1250 mm
Travel Y-axis: 900 mm
Spindle speed: 0 - 1120 /min.
Cooling through spindle: NO
Spindle travel - W axis: 680 mm

DBM 100 N
DEFUM
Inventory number: 231421

YOM:1999
Control system Fanuc: 16-M
Diameter of working spindle: 100 mm
Travel X-axis: 1830 mm
Travel Y-axis: 1500 mm
Spindle speed: 5 - 2000 /min.
Cooling through spindle: NO

WF 13 R
Fermat
Inventory number: 231958

YOM:2014
Control system Heidenhain: TNC 530
Diameter of working spindle: 130 mm
Travel X-axis: 12000 mm
Travel Y-axis: 3500 mm
Spindle speed: 10 - 3000 /min.
Spindle travel - W axis: 730 mm

BFT 90/3
UNION
Inventory number: 241213

YOM:1981
Control system Heidenhain:
Diameter of working spindle: 90 mm
Travel X-axis: 1600 mm
Travel Y-axis: 1210 mm
Spindle speed: 4 - 1600 /min.
Cooling through spindle:

WHN 11
TOS Varnsdorf
Inventory number: 241261

YOM:1977
Diameter of working spindle: 110 mm
Travel X-axis: 1600 mm
Travel Y-axis: 1250 mm
Spindle speed: 7 - 900 /min.
Cooling through spindle: NO
Spindle travel - W axis: 630 mm

WHQ 13 CNC
TOS Varnsdorf
Inventory number: 241188

YOM:2006
Control system Heidenhain: TNC 530
Diameter of working spindle: 130 mm
Travel X-axis: 3500 mm
Travel Y-axis: 2500 mm
Spindle speed: 1 - 3000 /min.
Cooling through spindle: YES

WHN 9 B
TOS Varnsdorf
Inventory number: 231773

YOM:1975
Diameter of working spindle: 90 mm
Travel X-axis: 1250 mm
Travel Y-axis: 900 (1120) mm
Spindle speed: 1120 - /min.
Cooling through spindle: NO
Spindle travel - W axis: 680 mm

WHN 13 P CNC
TOS Varnsdorf
Inventory number: 191459

YOM:2024
Control system Heidenhain: TNC 640
Diameter of working spindle: 130 mm
Travel X-axis: 3500 mm
Travel Y-axis: 2000 mm
Spindle speed: 10 - 3000 /min.
Cooling through spindle: YES

WH 10 CNC
TOS Varnsdorf
Inventory number: 171452

Control system Heidenhain: TNC 530
Diameter of working spindle: 100 mm
Travel X-axis: 1250 mm
Travel Y-axis: 1100 mm
Spindle speed: 10 - 1200 /min.
Cooling through spindle: NO

PC W 200 HA
ŠKODA MACHINE TOOL a.s.
Inventory number: 211378

YOM:1987
Diameter of working spindle: 200 mm
Travel X-axis: 5000 mm
Travel Y-axis: 4000 mm
Spindle speed: 0 - 630 /min.
Spindle travel - W axis: 2 000 mm
Cooling through spindle: NO

WHQ 13.8 CNC
TOS Varnsdorf
Inventory number: 211827

YOM:1989
Control system ECS:
Diameter of working spindle: 130 mm
Travel X-axis: 3500 mm
Travel Y-axis: 2000 mm
Spindle speed: 0 - 1200 /min.
Cooling through spindle: NO

WHQ 13.8
TOS Varnsdorf
Inventory number: 241075

YOM:2013
Control system Siemens: Sinumerik 840D Sl
Diameter of working spindle: 130 mm
Travel X-axis: 4000 mm
Travel Y-axis: 2500 mm
Spindle speed: 0 - 3000 /min.
Cooling through spindle: NO

WHN 13 CNC
TOS Varnsdorf
Inventory number: 241129

YOM:1991
Control system NCT:
Diameter of working spindle: 130 mm
Travel X-axis: 3500 mm
Travel Y-axis: 2000 mm
Spindle speed: 1 - 900 /min.
Cooling through spindle: NO

123

Horizontal boring machines are universal machines used for machining of complex products. These borers are mainly used for small batch production. For one workpiece clamping, the operation can be performed from up to five sides, either simultaneously or sequentially. A large number of standard and special accessories are available for horizontal boring machines. This makes boring machines suitable not only for boring, but also for drilling, turning, milling and other operations.

Horizontal boring machines can be divided into several types, such as:  table, cross, plate, coordinate. Can be divided also according to the type of control - conventional (without system), or CNC controlled.

Table type boring machines

Table boring machines are equipped with a movable table that moves in one or two axes. Depending on this, boring machines are further divided into cross-construction or T-construction. The table is usually rotary (B axis), which allows four sides of the workpiece to be machined in one clamp. However, if the machine is equipped with an angle head (A and C axes) and the workpiece does not exceed the dimensions of the machine, five sides can be machined in one clamp. The boring milling machines differ from the table milling machines in particular by the extendable spindle (W axis).  Higher series often also have a movable headstock (V axis).

Cross-construction

The cross design is usually used on compact machines with a table capacity up to 5 tonnes, where the table moves in two mutually perpendicular axes (X,Z). These machines are usually lighter and less demanding to build the base, but are limited not only by the travel, but also by the capabilities of the stand and spindle. The diameter of the spindle here is usually between 75 and 125 mm.


T-construction

The T-design is a more rigid machine with a table capacity of up to 25 tonnes and longer axis travel, with the table moving only in the transverse axis towards the spindle (X), while the stand moves in the longitudinal axis (Z) towards the table. The diameter of the boring spindle is usually between 100 and 160 mm due to the heavier and bulkier workpieces.


Floor type boring machines

These kinds of boring machines are suitable and used for machining of the largest workpieces. Headstock is moving along the vertical guide of the column and column itself is moving along the bed perpendicular to the axis of the spindle. The workpiece is clamped immovably on a cast-iron floor plate equipped with T-slots. If this floor type boring machine is equipped with a rotary table which is movable in the direction of the spindle axis, the number of controlled axes increases. Such boring machines mainly have a boring spindle diameter of 130-315 mm

Coordinate boring machines

So-called coordinate boring machines are used for machining precise holes. Its design is affected by the requirements for very high accuracy of all movements, good dynamics and the best possible temperature stability. There are two types of these machines. One-column borer with horizontal or vertical spindle axis (this is for smaller sizes of workpieces that are clamped on a cross table) and two column borer with one or more vertical spindles. Workpiece is clamped on a longitudinal table, which is in between two columns along which the crosspiece carrying the work headstock moves. An optical system is usually used for measuring. More modern machines are then equipped with a CNC control system.

All types of horizontal boring machines are conventional or CNC controlled. Among the most popular producers of CNC systems are Heidenhain, Siemens, Fanuc, Fagor.

Horizontal boring machines can be also equipped with automatic tool change which is primarily used for storage of tool holders, its manipulation and positioning without participation of human factor.

Among the main and most popular manufacturers of boring mills we have to mention:  FERMAT, TOS, ŠKODA, PAMA, UNION, JUARISTI, SCHARMANN, KURAKI, WOTAN.
