Année de production:1988
Max. diamètre a meulager: 280 mm
Longueur maxi de meulage: 630 mm
Poids maxi de la piece a usiner: 60 kg
Equipement pour meulage intérieure:
Poids totale de la machine: 3000 kg
Max. diamètre a meulager: 250 mm
Longueur maxi de meulage: 1500 mm
Poids maxi de la piece a usiner: kg
Equipement pour meulage intérieure: NON
Hauteur maxi de meulage: 125 mm
Dimensions de la table: 2060 x 140 mm
Longueur maxi de meulage: 1000 mm
Largeur maxi a meulage: 320 mm
Hauteur maxi de la piece a usiner: 350 mm
Type de fixation de la broche: Horizontální
Puissance du moteur principal: 4 kW
Puissance d´entré: 6,8 kVA
Année de production:2016
Max. diamètre a meulager: 300 mm
Longueur maxi de meulage: 600 mm
Poids maxi de la piece a usiner: 150 kg
Equipement pour meulage intérieure: OUI
Vitesse de la broche de meulage: 10 - 300 /min
Puissance du moteur principal: 3,7 kW
Année de production:1987
Max. diamètre a meulager: 320 mm
Longueur maxi de meulage: 1500 mm
Poids maxi de la piece a usiner: 350 kg
Equipement pour meulage intérieure: NON
Puissance d´entré: 16 kVA
Dimensions hors tout: 4190 x 1976 x 1668 mm
Année de production:2011
Système de contrôle Fanuc: 0i - TC
Max. diamètre a meulager: 190 mm
Longueur maxi de meulage: 400 mm
Poids maxi de la piece a usiner: 80 kg
Equipement pour meulage intérieure: OUI
Dimensions hors tout: 2500 x 1900 x 1800 mm
Année de production:2022
Système de contrôle Siemens: Sinumerik 840D Sl
Max. diamètre a meulager: 500 mm
Longueur maxi de meulage: 2000 mm
Poids maxi de la piece a usiner: 500 kg
Equipement pour meulage intérieure: OUI
Puissance du moteur principal: 11 kW
Année de production:2007
Système de contrôle Siemens: Sinumerik 840 D
Max. diamètre a meulager: 350 mm
Longueur maxi de meulage: 600 mm
Poids maxi de la piece a usiner: 80 kg
Equipement pour meulage intérieure: NON
Course X: 400 mm
Grinding is a technology of precision chip machining. Nowadays, it is possible to reach precision in order of tenths of micrometers and surface roughness of up to 0,2 micrometer. Grinders are thus indispensable in the machinery industry and form an important part of the production process. In general, grinding is a technology that works on the principle of the material removal from the surface layer of the workpiece with fine grains of abrasive material, which are most often bonded to the grinding wheel.
Among the cylindrical grinders we differentiate grinders with centers and without centers. These machines are used for grinding internal and external rotating surfaces.
In case of center grinders the workpiece is usually clamped between centers and rotation is realized using a driver, which is fixed to the surface of the workpiece and tied to headstock. In most cases the workpiece rotates against the direction of rotation of the grinding wheel. Most common models from producer TOS we can mention:
Grinding is realized using the rotation of the grinding wheel, which grinds the surface of the workpiece as it rotates. Most popular producers of such grinders are: FERMAT, TOS, STUDER, DANOBAT, KELLENBERGER, ERWIN JUNKER, SCHAUDT.
Centerless grinders are also intended for grinding rotary surfaces. The clamping of the workpiece on the machine is different. It is supported with support ruler and the workpiece is placed between two discs – abrasive and drifting. The grinding wheel usually spins faster and does the grinding itself. The drive disc is most often made of flexible material (for example rubber) and ensures sufficient pressure.
A special category of grinders are grinders used for grinding of internal rotating surfaces. They works similarly to center grinders. However, the workpiece is just clamped on one side in the chuck or collet so that the hole can be ground from the other side.
