Name of a product | Inventory number | Producer | YOM | Parameters | ||
---|---|---|---|---|---|---|
FV 25 CNC |
241025 | OSO - Olomouc | 1995 | Control system Heidenhain: TNC 360 Dimensions of table working surface: 1300x350 mm Travel X-axis: 660 mm Travel Y-axis: 355 mm Travel Z-axis: 420 mm Rapid feed: 7000 m/min |
||
FGS 32/40 |
151492 | TOS KUŘIM - OS, a.s. | 1991 | Table dimensions: 1400x400 mm Travel X-axis: 1000 mm Travel Y-axis: 400 mm Travel Z-axis: 450 mm Spindle taper: ISO50 . Main motor power: 11 kW |
||
FNGJ 40 |
192102 | Intos | 1995 | Dimensions of table working surface: 800x400 mm Travel X-axis: 600 mm Travel Z-axis: 400 mm Spindle speed: 63 - 3150 /min. Spindle taper: SK40 . Machine weight: 2200 kg |
||
FX 25/01 |
241178 | GOGLIO | 2001 | Control system Selca: 4045 Dimensions of table working surface: mm Travel X-axis: 2500 mm Travel Y-axis: 1300 mm Travel Z-axis: 1300 mm Max. load of table: 4000 kg |
||
Spazio 25/L |
221792 | FPT INDUSTRIE S.p.A. | 1997 | Control system Heidenhain: Dimensions of table working surface: 2200x750 mm Travel X-axis: 2500 mm Travel Y-axis: 1250 mm Travel Z-axis: 800 mm Spindle taper: ISO 50 . |
||
FGS 25/32 |
231448 | TOS OLOMOUC, s.r.o. | Dimensions of table working surface: 1000x320 mm Travel X-axis: 720 mm Travel Y-axis: 360 mm Travel Z-axis: 420 mm Spindle taper: ISO 40 . Main motor power: 5,5 kW |
|||
FV 30 CNC |
241112 | TOS OLOMOUC, s.r.o. | Control system Heidenhain: Dimensions of table working surface: 1300x305 mm Travel X-axis: 760 mm Travel Y-axis: 381 mm Travel Z-axis: 450 mm Spindle taper: ISO 40 . |
|||
SMX 3500 |
231931 | XYZ | 2015 | Dimensions of table working surface: 1370 x 356 mm Travel X-axis: 787 mm Travel Y-axis: 508 mm Travel Z-axis: 508 mm Spindle speed: 0 - 5000 /min. |
||
FNGJ 32 |
231461 | Intos | 1987 | Dimensions of table working surface: 800 x 400 mm Travel X-axis: 600 mm Travel Y-axis: 400 mm Travel Z-axis: 400 mm Main motor power: 3 kW Spindle speed: 40 - 2000 /min. |
||
FGS 25/32 |
231045 | OSO - Olomouc | 2003 | Dimensions of table working surface: 320 x 1000 mm Travel X-axis: 720 mm Travel Y-axis: 360 mm Travel Z-axis: 420 mm Spindle taper: ISO 40 . Machine dimensions l x w x h: 2560x2560x1820 mm |
||
FSGQ 80 A - SM/A2 |
221719 | TOS KUŘIM - OS, a.s. | 2007 | Control system Heidenhain: TNC 530 Dimensions of table working surface: 800 x 2000 mm Travel X-axis: 2000 mm Travel Y-axis: 900 mm Travel Z-axis: 800 mm Spindle taper: HSK 63 . |
||
TM-2 HE |
221773 | Haas Automation | 2007 | Control system Haas: Dimensions of table working surface: 1467x267 mm Travel X-axis: 1016 mm Travel Y-axis: 406 mm Travel Z-axis: 406 mm Spindle speed: 0 - 4000 /min. |
||
FSQ 80 CNC |
231270 | TOS KUŘIM - OS, a.s. | 2007 | Control system Heidenhain: TNC 410 Dimensions of table working surface: 2000 x 880 mm Travel X-axis: 2000 mm Travel Y-axis: 800 mm Travel Z-axis: 900 mm Main motor power: 30 kW |
||
UFZ 4 |
211711 | SHW Werkzeugmaschinen | 2007 | Control system Heidenhain: TNC 530 Dimensions of table working surface: 2500x800 mm Travel X-axis: 2500 mm Travel Y-axis: 1300 mm Travel Z-axis: 900 mm Milling head: YES |
||
LEM 935 |
231628 | FPT INDUSTRIE S.p.A. | Control system Heidenhain: TNC 407 Dimensions of table working surface: 3000x920 mm Travel X-axis: 2500 mm Travel Y-axis: 1000 mm Travel Z-axis: 1000 mm Spindle speed: 1 - 3000 /min. |
|||
MFU 10000 |
231885 | ZAYER | Control system Heidenhain: TNC 426 Dimensions of table working surface: 10 000x1000 mm Travel X-axis: 8000 mm Travel Y-axis: 1250 mm Travel Z-axis: 1500 mm Max. weight of workpiece: 10 000 kg |
|||
BFM 260 CNC |
231145 | RAFAMET S.A. | 2005 | Control system Heidenhain: TNC 530 Dimensions of table working surface: 2600 x 1270 mm Travel X-axis: 2600 mm Travel Y-axis: 1000 mm Spindle taper: ISO 150 . Machine dimensions l x w x h: 7450 x 5000 x 3535 mm |
||
FGS 32/40 |
231699 | TOS KUŘIM - OS, a.s. | 1987 | Dimensions of table working surface: 400x1400 mm Travel X-axis: 1000 mm Spindle taper: ISO 50 . Milling head: YES Max. weight of workpiece: 800 kg Spindle speed: 35 - 1800 /min. |
||
FNGJ 20 |
231884 | Intos | 1994 | Dimensions of table working surface: 400 x 256 mm Travel X-axis: 450 mm Spindle taper: SK 40 . Travel Y-axis: 300 mm Travel Z-axis: 350 mm Spindle speed: 0 - 3150 /min. |
||
FGS 40 CNC |
241061 | Strojtos | 1997 | Control system Heidenhain: TNC 415 Dimensions of table working surface: 400x1120 mm Travel X-axis: 900 mm Travel Y-axis: 400 mm Travel Z-axis: 450 mm Spindle taper: ISO 50 . |
||
CN-4AX-2SP |
231189 | Cinncinaty Milacron | 1978 | Control system Acramatic: 2100 CNC Dimensions of table working surface: 6096 x 3048 mm Travel X-axis: 6096 mm Clearance between columns: mm Distance between table and cross-rail: 711 mm Travel Y-axis: 3048 mm |
||
FNGJ 20 |
241026 | TOS OLOMOUC, s.r.o. | 1986 | Dimensions of table working surface: 600 x 300 mm Travel X-axis: 450 mm Spindle taper: SK 40 . Travel Y-axis: 300 mm Travel Z-axis: 350 mm Spindle speed: 63 - 3150 /min. |
||
FX 15/98 |
241177 | GOGLIO | 1999 | Control system Selca: 3045 Dimensions of table working surface: mm Travel X-axis: 1500 mm Travel Y-axis: 800 mm Travel Z-axis: 700 mm Tool magazine: YES |
||
BF-300 |
221593 | CME | 2003 | Control system Heidenhain: TNC 426 Dimensions of table working surface: 2400x850 mm Travel X-axis: 2500 mm Travel Y-axis: 1100 mm Ram travel (Z): 1200 mm Cooling through spindle: NO |
||
FGS 32 |
231371 | TOS KUŘIM - OS, a.s. | 1984 | Dimensions of table working surface: 400x1000 mm Travel X-axis: 1000 mm Travel Y-axis: 400 mm Travel Z-axis: 450 mm Main motor power: 7,5 kW Machine dimensions l x w x h: 3180x3310x2400 mm |
Console type – console is moving here in the vertical Z axis and supporting a cross table which is moving along X and Y axis.
Tool type – compact one, mainly for tool shops.
Table type – with the larger table which is moving along the bed in traverse direction on X axis with retractable headstock in Y axis suspended from the column along which it moves in the vertical direction of the Z axis. For machining the milling head is used and can be adjusted horizontally or vertically. Milling head can be also indexed in the B axis, or continuously controlled in two axes.
Plano type – with a two-column gantry carrying a crossbar with a spindle moving along it in the Y axis and retractable in the Z axis. Further it is divided into:
Rolling type – for production of the gears.
Milling machine can be controlled manually using buttons, levers and wheels. More modern ones are equipped with digital readout of X,Y,Z axes or with regular CNC control. Most common are systems from producers HEIDENHAIN, SIEMENS, FANUC or FAGOR.
The most famous and traditional brand of milling machines in Czech Republic is TOS Kurim, which is manufacturing wide range of milling machines from small tool machines to the largest portal ones. Not even TOS Kurim is engaged in manufacturing such machines. There are also other TOS companies such as – TOS Olomouc a TOS Čelákovice, or INTOS. Among the world manufacturers of milling machines SHW, CME, MTE, SORALUCE a ZAYER, Italian EMCO or American producer LAGUN.
In case of portal milling machines the main competitor of TOS is Taiwan company HARTFORD, KAO MING, LEADWELL or SMTCL, furthermore German WALDRICH COBURG, Spanish producers CORREA a SORALUCE, or MAZAK and OKUMA from Japan which are using their own CNC systems same as HAAS or HURCO does.
