Sonstiges / Sonstige / VAIOCS 1G

Inventarnummer 231619
Maschinentyp VAIOCS 1G
Hersteller EMO
Baujahr 2009

Max. Werkzeugabmessungen	530x320x200 mm
Max. Werkstückgewicht	70 kg
	3000
Maschinenabmessungen L x B x H	2800x1750x2400 mm

Änderungen und Irrtümer in den technischen Daten, Angaben und Preisen sowie Zwischenverkauf vorbehalten.

Beschreibung

The machine is in excelent condition. Possible to test under power.
Cleaning process - dip-degreasing with solvent alternatively with ultrasonic.
- Immersion
- Intermediate drying
- Vapour degreasing
- Vacuum drying
All steps alternatively with basket motion
Batch dimensions 530 x 320 x 200 mm
Performance 8-10 batches/h (normal programme)
Batch weight max. 70 kg
Solvent hydrocarbon, modified alcohol
Content Solvent approx. 450 litres
Electrical output:
Heat output 33 kW
Motor output 13 kW
Cooling output approx. 15 kW
power requirement approx. 51 kW / 90 A
Operating voltage 400 V / 50 Hz / 3/N/PE
Pressurised air approx. 6 bar
Amount of exhaust airapprox. 63 m3/h
