Lathes / Centre to diameter 800 mm / SN 50 B/2000

Lathes / Centre to diameter 800 mm / SN 50 B/2000

  • Inventory number 191909
  • Machine type SN 50 B/2000
  • Producer TOS Trenčín
Swing over bed500 mm
Distance between centres2000 mm
Max. weight of workpiece600 kg
Swing over cross slide270 mm
Main motor power5,5 kW
Machine dimensions l x w x h1100 x 3575 mm
Machine weight1845 kg

Subject to change of technical parameters.


Description

The machine is in good technical condition, under power, after agreement is possible to test it. After general repair 7/2019.
Accuracy protocol, electrical inspection report.

Similar machines

EE 500 / 1500
YOM: 0
Swing over bed540 (710) mm
Distance between centres1500 mm
Max. weight of workpiece kg
Swing over cross slide300 mm
Spindle bore72 mm
Main motor power11 kW
Machine dimensions l x w x h3360x1360x1405 mm
Machine weight3450 kg
Control systemNO

EE 500 / 1500
SZIM
Inventory number: 192122

2TAP
YOM: 1960
Swing over bed710 mm
Distance between centres3500 mm
Max. weight of workpiece10000 kg
Spindle bore60 mm
Spindle speed1 - 95 /min.
Main motor power25 kW
Machine weight25000 kg
Control systemNO

2TAP
Poreba
Inventory number: 192100

SUS 80/6500
YOM: 1979
Swing over bed840 mm
Distance between centres6500 mm
Max. weight of workpiece6000 kg
Swing over cross slide530 mm
Main motor power18,5 kW
Machine weight7200 kg
Machine dimensions l x w x h5800 x 1445 x 1880mm mm
Control systemNO

SUS 80/6500
TOS Čelákovice
Inventory number: 201037

SU 50A
YOM: 1971
Swing over bed500 mm
Distance between centres1500 mm
Max. weight of workpiece850 kg
Spindle bore56 mm
Spindle taperMorse 6 .
Spindle speed11 - 1400 /min.
Machine weight3110 kg
Machine dimensions l x w x h1180x3900 mm
Main motor power11 kW
Control systemNO

SU 50A
TOS KUŘIM - OS, a.s.
Inventory number: 191798

SU 50 / 2000
YOM: 0
Swing over bed500 mm
Distance between centres2000 mm
Max. weight of workpiece1100 kg
Swing over cross slide250 mm
Main motor power11 kW
Spindle bore56 mm
Spindle speed1400 - /min.
Machine dimensions l x w x h4420 x 1180 mm
Machine weight3260 kg
Control systemNO

SU 50 / 2000
TOS Trenčín
Inventory number: 201209
