Prese / Excentric pînă la 100 T / T40 FNGV

• Număr inventar 261372
• Tipul mașinii T40 FNGV
• Producător Legnani
• An fabricație 1989

SOLICITARE PRODUS

Parametrii tehnici pot fi modificați.

Descriere

• Maximum pressing force: 40 t (400 kN)
• Maximum slide stroke: 100 mm
• Main motor power: 3 kW
• Slide adjustment: Up to 50 mm.
• Number of strokes: Standard operation at approximately 100–120 strokes per minute (depending on drive design).
• Distance between table and cup (PMI): Up to 380 mm at maximum distance.

Construction features
• Frame: Cast iron or welded steel structure with a swan neck (C-frame), which allows access to the work table from three sides.
• Clutch and brake: Models in this series are equipped with a pneumatic clutch-brake, which ensures safe and quick stopping of the cup.
